Marine Services Equipment, Marine Towing

American Islander

DOWNLOAD SPEC SHEET

American Islander

American Islander Cargo Tows

Year Built: 1970 by Bender Marine (Complete rebuild 2002), Repower 2020

Dimensions: 100′ x 24′ x 12′

Deck Space: Clear Deck Space 1100 sq. ft. 55 Long Tons of Cargo

Main Propulsion: 2 Caterpillar C32 Tier 3, Combined 1600 HP

Generators: 40 Kw, 110/220 Volts, John Deere

Speed: 12 Knots

Fuel Capacity: 21,000 Gallons 086 Tons

Fuel Consumption: 50 GPH

Potable Water: 26,263 Gallons 100 Tons

After Station: Yes

Jet/Fire Monitor: Jet/Fire Pump 6″ Deming Drive by Cummins QSB 6.7 Tier 3. 305 HP, 1-1/2″ Nozzle at 130 PSI.

Hydraulic “A” Frame: 15 Ton Articulating “A” Frame

Hydraulic Crane: 12 Ton Hydraulic Crane

Deck Winch: Hydraulic Single Drum w/Single Capstan.
Capacity: 1500′ of 1-3/8″ Wire Line Pull at 25 RPM 25,000 LBS at 12 1/2 RPM 50,000 LBS

Bow Winch: Hydraulic Single Drum w/Double Capstan 1300′ of 7/8″

Wire Electronics: Two (2) Radar, Single Side Band Radio, Two (2) VHF Radios, One (1) Private UHF Radio, Auto Pilot, GPS, 50 MHz Depth Sounder, SAT Phone

Accommodations: USCG certified for 27 passengers

Gross Tons: 98 Tons

Light Ship Tons: 177 Tons

Official Number: 529 318

Dwt (1/2 F&W): 281

Tons Area of Operations: Oceans, Coastwise, Lakes, Bays, and Sounds

Bollard Pull: 010 Tons

Marine Services Equipment, Marine Towing

American Contender A MEMBER OF AWO’S RESPONSIBLE CARRIER PROGRAM

DOWNLOAD SPEC SHEET

American Contender

Year Built: 1966 Maine Ironworks rebuilt/repowered 2004

Dimensions: 100′ x 28′ x 11′

Main Propulsion: Two (2) D-3512B Turbo-Charged Caterpillar Diesels, Twin Srew 2600 HP

Generators: Two (2) John Deere 40KW

Reduction Gears: ZF Mason 4.608:1 Gears

Propellers: 88″ x 72″ 4-Blade S.S. Avondale Wheels

Speed: 11 knots

Fuel Capacity: 48,250 Gallons

Water Capacity: 15,000 Gallons

Lube Oil Capacity: 700 Gallons

Electronics: Gyro Compass w/Auto Pilot, Two (2) Radars, Two (2) VHF’s, One (1) Single Side Band Radio w/24 Hour NECODER Ringer System, Two (2) Fathometers, Trimple NAV System, Cell Phone, Weather Fax

Towing Winch: INTERCON Double Drum Winch w/1,800′ x 1-3/4″ Steel Core Cable w/1,500′ x 1-3/4″ Steel Core Cable on Second Drum, set up for Anchor Handling w/Stern Rollers

Gross Tons: 146 Tons

Light Ship Tons: 240 Tons

Net Tons: 99 Tons

DWT: 360 Tons

Call Letters: WBO 8595

Official Number: 502 231

Area of Operations: Oceans, Coastwise, Lakes, Bays, and Sounds

Marine Services Equipment, Marine Towing

American Champion

Posted on by

Champion-towing-Punapau-AMC-ocean-cargo-towing-service

DOWNLOAD SPEC SHEET

American Champion

Marine Services Equipment, Marine Towing

American Challenger

Posted on by

Challenger-towing-544-hawaii-to-ensenada

DOWNLOAD SPEC SHEET

American Challenger

Barges, Marine Services Equipment

AWB 240

Posted on by

AWB240

awb-240-flat-deck-barge-with-sand-load-2021

DOWNLOAD SPEC SHEET

Type: Flat Deck Barge
Dimensions: 242′ x 60 x 15.4′ / Open Deck 226′ x 54′
Ramp: Certified 50-Ton, Two Sections, Side load or Stern load
Classification: ABS Load Line
Certification: USCG Certificate of Inspection
Gross Tons: 1804 Tons
Net Tons: 1804 Tons
Cargo Capacity: 4400 Tons, 5′ High Structual Binwall
Pump Room: Active Ballast and Trim Tank System
Breakwater: 14′ High
Official Number: 580276
Area of Operations: Coastwise, Registry
